UNIMOTION
Ironless linear motors

High force density

Force density is up to 25% higher in comparison to our competitors.

Low force ripple

Thanks to the robust design the UNIMOTION ironless motors achieve an extremely low force ripple.

Best price-performance ratio

UNIMOTION ironless motors have a great price-performance ratio.

High dynamic applications

UNIMOTION ironless motors are ideal for a variety of high-dynamic applications.

Hall sensor

AD Hall Sensor

UNIMOTION LML Hall Sensors are the only ones on the market with integrated Analog and Digital sensors.

Free wake & shake

The innovative design of a Hall sensor enables a free wake & shake feature.

Buy Learn more

Online sizing tool

Online sizing tool

A sophisticated sizing tool provides you with a solution in only a few minutes.

Endless Configuration

Configuration tool

The Linear motor system can be configured through the Easy to use, Step-by-Step configuration tool.

3D model generation

The integrated 3D generation solution allows instant preview and download of the configured system in more than 50 formats.

Online ordering

The configured Linear motor system can be easily purchased through the UNIMOTION online shop.

Linear motors

Linear motor sizes

UNIMOTION provides 4 different sizes of ironless linear motors.

Linear motor versions

Each ironless linear motor size is available in up to 5 different versions all in high and low-speed types.

High and low speed

High-speed motors offer a nearly 230 % increase in maximum velocity compared to low speed.

No cogging and no attraction force

Thanks to the ironless core there is no attraction force between the motor and the magnet plate and no cogging effect.

Buy

Magnet plates

Magnet plate sizes

UNIMOTION provides multiple sizes of magnet plates for various mounting combinations.

Multi mounting options

All magnetic plates have multi mounting options on the base: through holes and threads

Buy

Ironless linear motors specifications

CONTINOUS FORCE Up to 767 N
PEAK FORCE Up to 3069 N
CONTINOUS CURRENT Max 22,2 A / 325 VDC
PEAK CURRENT Max 89,0 A / 325 VDC / 1s
COIL TEMPERATURE Max 125°C
CABLE Flexible hybrid cable
HALL SENSOR Inovative AD Hall sensor design
Buy
